Insertion Electromagnetic Flow Meter

Insertion Electromagnetic Flow Meter

MOQ : 10 Pair

Business Type Manufacturer, Exporter, Supplier
Brand Name CBRO
Line sizes 50 mm to 3000 mm

Preferred Buyer From

Location Worldwide

Electromagnetic Flow measurement has been in use around the world for 50 years and more, as witnessed by the popularity of these meters that continues unabated in virtually all sectors of industry. Electromagnetic Flowmeters can be used to measure all electrically conductive liquids (> 5 µS/cm) with or without solids, e.g. water, wastewater, sludge, slurries, pastes, acids, alkalis, juices, fruit pulp, etc.



Insertion Type Electromagnetic Flowmeter is suitable for the most demanding applications. They are based on Faraday’s law of Electromagnetic Induction. The meter features sensor tube and ball valve assembly.



Salient Features:

  • Based on Faraday’s law of electromagnetic induction
  • Flow tube sizes 100 mm to 600 mm
  • Coil assembly in hermetically sealed welded construction
  • Integral or remote transmitter
  • Field interchangeable electronics
  • High linearity due to characteristic magnetic field
  • Absolute zero stability and noise elimination due pulsed DC excitation



Applications:

  • Chemical, petrochemical and process industries
  • Fertilizer industries
  • Pharmaceutical industries
  • Sugar, beverage industries

Yes! I am interested


Technical Specifications

Parameters Specifications
Nominal dia (mm) > 100
Working pressure (kg/cm2) 20
Working temperature Up to 120oC
Electrode material SS 316L Std.*
Sensor lining NA
Display version Integral/Remote
Measuring tube material SS 316 Std.*
Sensor housing material NA
End connection NA
Flange standard NA
Measuring range 0.2 to 12 m/sec. Bidirectional
Accuracy % of measured value ±2%
Repeatability ±0.2% of Span
Display 2 line LCD
Display units All standard engineering units in m3, litre, gallon, ft3, imperial gallon
Output Std. 4 – 20 mA*
Power supply 12 – 60 V DC or 80 – 300 V AC/DC Solar powered
Protection class for sensor Std. IP 68
Protection class for transmitter IP 67
Cable length for remote Std. 10 m*
Installation Insertion type with use of isolating ball valve assembly on pipeline
