| Business Type | Manufacturer, Exporter, Supplier |
| Make | CBRO |
| Model | VFM250 |
| VFM250 | Liquid / Gas / Steam |
| Click to view more | |
Preferred Buyer From
| Location | India, United Arab Emirates, Netherlands Antilles, Bangladesh, Bahrain, Bulgaria, Viet Nam, Australia, Cyprus, Germany, Egypt, Algeria, Spain, Indonesia, Israel, Ireland, Iraq, Jordan, Kuwait, Lebanon, Mauritius, Oman, New Zealand, Portugal, Qatar, Romania, Saudi Arabia, Sudan, El Salvador, Thailand, Tunisia, Turkey, Ukraine, Uganda, United States, Uzbekistan, Yemen, Zambia |
Product Details
Diameter
10,15,20,25,32,40,50,65,80,100,150,250,300,(300~1000)
Temperature
Piezoelectric:-40~60ºC Capacitive:-40~300ºC
Material
Stainless steel material
Vibration Acceleration
Piezoelectric:0.2g Capacitive:1.0~2.0g
Accuracy
1.0%FS;1.5%FS; Insert type:2.5%FS
Flow ratio
1:6~1:30
Power supply
Flow Sensor:12VDC/24VDC / Battery: 3.6V
Output
Pulse ,4~20mA Output ; Battery supply can not provide any output
Explosion
ExdIIia CT2~T5 or ExdII CT2~CT5
Protection
IP65 or IP68
CBRO vortex flowmeter is used for measuring the flow velocity of gases or liquids in pipelines flowing full. The measuring principle is based on the development of a Karman vortex shedding street in the wake of a body built into the pipeline. The periodic shedding of eddies occurs first from one side and then from the other side of a bluff body (vortex-shedding body) installed perpendicular to the pipe axis. Vortex shedding generates a so called "Karman vortex street" with alternating pressure conditions whose frequency is proportional to the flow velocity.
Features:
- Lattice LCD display
- Easy operation
- Configure with temperature/pressure senor. For temperature sensors, Pt100 or Pt1000; For pressure sensor, gauge pressure sensor or absolute pressure sensor
- Multiple Outputs can be optional: Two-Wire 4-20mA, Three-Wire pulse and Three-Wire equivalent output
- Excellent nonlinearity correction function, greatly improve the appearance of linearity
- Spectral analysis, improve the ability of anti-interference and vibration resistance
- A variety of measuring medium: vapor, liquid, gas and natural gas, etc.
- Low power consumption, a dry cell can maintain at least 3 years
- Automatic switching ability of the working modes: Battery supply, Two-Wire and Three-Wire
- Self-checking function: the rich self-checking information make easy maintenance and debugging
- Independent password setup, the parameters setup, total flow reset and calibration can be set with different- level passwords, it is convenient for management
- Three-Wire system supports RS485 communication The display unit can be selected and user-defined
Technical Specifications
| Diameter Nominal (mm) | Liquid | GAS & STEAM | ||
| Measuring Range(m3/h) | Frequency Range(Hz) | Measuring Range(m3/h) | Frequency Range(Hz) | |
| 10 | 1.1~14 | |||
| 15 | 0.3~5 | 35~600 | 2.2~20 | 260~2000 |
| 20 | 0.6~10 | 29~420 | 4~36 | 210~1900 |
| 25 | 1.2~16 | 25~336 | 8.8~50 | 190~1140 |
| 32 | 1.8~20 | 18~264 | 10~150 | 156~1080 |
| 40 | 2~40 | 10~200 | 27~205 | 140~1040 |
| 50 | 3~60 | 8~160 | 35~380 | 94~1020 |
| 65 | 4~85 | 6~120 | 35~800 | 94~940 |
| 80 | 6.5~130 | 4.1~82 | 86~1100 | 55~690 |
| 100 | 15~220 | 4.7~69 | 133~1650 | 42~536 |
| 125 | 20~350 | 3.2~57 | 150~2000 | 38~475 |
| 150 | 30~450 | 2.8~43 | 347~4000 | 33~380 |
| 200 | 45~800 | 2~31 | 560~8000 | 22~315 |
| 250 | 65~1250 | 1.5~25 | 890~11000 | 18~221 |
| 300 | 95~2000 | 1.2~24 | 1360~18000 | 16~213 |
