Turbine Flow Meter

Turbine Flow Meter

MOQ : 10 Piece

Business Type Manufacturer, Exporter, Supplier
Line Size 6 NB to 250 NB
Measuring Range 0.18 to 750 m3/hr of water / clear liquid 0.5 to 2200 Nm3/hr of Air/Gas at NTP
Display 4 Digit LED for flow rate & 8 Digit LED for totaliser
Click to view more

Preferred Buyer From

Location Worldwide

Product Details

Transmitter Electronics
Integral / Remote
Accuracy
+1- 1% F.S. (0.5% Optional)
Linearity
+/-0.5%
Repeatability
+/-0.2%
Turn down ratio
10 : 1 to 100 : 1
Density / Sp. Gravity
Up to 2.95
Viscousity
Up to 100 cp
Process Temperature
0-80 Deg C (Special design for high temerature available)
Process Pressure
0-20 Kg/cm2 (Special design for high pressure available)
Material of construction
Bearings Tungsten Carbide Sleeve / Rotor ½ SS 410
Power Supply
24 V DC, External / Battery Powered / Solar Powered
Power Consumption
< 1 VA
Response Time
< 100 m Sec
Temperature Coefficient
+/-0.01 % per 0C
Transmitter Enclosure
Flame-proof, IP-65, IIA, IIB CMRI certified
Mounting
Flush of Panel
Communication
RS485 Modbus / GPRS / Wifi
Series
TFM250

CBRO make TFM250 series Turbine Flow Meter  are designed for the volumetric measurements of liquids & gases. The meters are rugged, reliable & precise instruments suitable for all industrial corrosive & Non – Corrosive Chemicals, Fuels, and Oil & Gases etc. The basic meter consists of a freely suspended bladed rotor positioned axially in the flow stream with the flowing fluid pushing against the blades. The rotational speed of the turbine is proportional to the velocity of the fluid & hence truly represents the volume of the fluid flowing through meter. The rotation of turbine rotor generates electrical pulses in the pick off attached to flow meter housing. The output pulses are amplified & converted to measure flow rate & integration. Turbine sensor with four/six digit batch controller with ICO Relay output contact offered to transfer. Preset qty. Of liquid from main storage tank with automatic flow shut off. We are a credible Manufacturer, Exporter and Supplier of Turbine Flow Meter in India.



Applications:

  • Water
  • Diesel
  • Petrol
  • Vegetable Oil
  • Hydraulic Oil
  • Chemical (S.S. With Teflon coating)
  • Milk plant.
  • Air
  • Gases
