Pressure Transmitters
Leading Manufacturers, Exporters, Wholesaler, Retailer and Trader of Differential Pressure Transmitter, Digital Pressure Transmitter, Flange Mounted Differential Pressure Transmitter, Pressure Transmitter and Smart Type Pressure Transmitter from Thane.
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Measure Range | 0 ~ 1KPa ~ 3MPa |
| Indication Resolution | 0.075% |
| Ambient Temperature | -40 ~ 85 ℃ |
| Output Signal | 4-20ma analog output / with HART communication |
| Shell protection | IP67 |
| Diaphragm Material | Stainless Steel 316l, Hastelloy C, Support other Custom |
| Product Shell | Aluminum Alloy, the Appearance of Epoxy Coating |
| Weight | 3.3Kg |
| Business Type | Manufacturer, Supplier |
| Make | CBRO |
| Model | DPT8800 Series |
| Pressure range | -1~0~1bar; 0-1bar~0-2000bar |
| Over load | 150%FS |
| Burst pressure | 300%FS |
| Output | 4-20mA |
| Power Supply | 12~36VDC |
| Response time | <5ms |
| Combine error | 0.5% FSO(Including Linearity, Repeatability & Hysteresis) |
| Pressure connection | M20×1.5, G1/2 , G1/4 ,1/2NPT （ customer tailor ） |
| Operating temperature | -20℃ ～ 85℃ |
| Temperature compensation | 0℃ ～ 60℃ |
| Electrical connector | Terminal Block |
| Explosion proof grade | ExiallCT4 |
CBRO high performance pressure transmitter is suitable to measure liquid, gas, or steam flow as well as liquid level, density and pressure. It outputs a 4~20mADC signal corresponding to the measured pressure.Its highly accurate and stable sensor can also measure the static pressure which can be shown on the integral indicator or remotely monitored via HART communications. Other key features include quick response, remote set-up using communications, self-diagnostics and optional status output for pressure high/low alarm.
- High accuracy, high stability
- Explosion proof grade ExibllCT4
- Local LCD display
This series product is suitable for the occasion of chemical fiber, environmental protection, medicine, industrial control and etc. It is used to measure the pressure or height of the liquid level of corrosive medium, such as acid, alkaline and so on.
Features:
- Stainless steel sealed construction
- Intrinsically safe
- Protection class-IP65
- Corosion resistant, with LCD display
- Short delivery time
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Measure Range | 0-6kPa~3MPa |
| Indication Resolution | 0.075% |
| Ambient Temperature | -40 ~ 85 ℃ |
| Output Signal | 4-20ma analog output / with HART communication |
| Shell Protection | IP67 |
| Diaphragm Material | Stainless steel 316L, Hastelloy C, support other custom |
| Weight | 3.3Kg |
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Model Number | CPT100 |
| Make | CBRO |
| Range | 0 - 0.05 TO 0 - 1,000 BAR (0 - 1 TO 0 - 15,000 PSI) |
| Housing Material | SS316 |
| Sensor Diaphragm | SS316 |
| Accuracy | ±0.1% of Span |
| Output | 4-20 mA, 0 to 5 mV and others |
| Supply | 24V DC |
| Non-Linearity | 0.25% or 0.5% |
| Process Connection | 1" NPT, 1/2" NPT, 1/4" NPT, 3/8" NPT, 3/4" NPT and others |
Adopts stainless steel shell structure, built in stainless steel oil filled sensor, intelligent digital circuit with precise temperature characteristic compensation, it can be used reliably and stably. It is suitable for gas, liquid, steam pressure measurement and pressure measurement with corrosive media, it can also be used for level measurement.
Introduction :-
- Process pressure measurement in measurement and control technology
- System pressure monitoring in liquids and gases, e.g., for leakage detection
- Pressure control for power control of pumps
- Indirect measurement of process-relevant metrics such as level, density, flow, or steam temperature
- Vacuum control in de-aerators
| Business Type | Manufacturer, Exporter, Supplier |
| Brand Name | CBRO |
| Country of Origin | India |
| Type | Pressure Transmitter |
| Protocol | HART |
| output signal | 4 To 20mA |
| Programming Interface | Three Buttons Or PC |
| Adjustable Parameters | Zero, Span, Decimal Point, Damping, Display Mode, Restore Data |
| Display | Liquid Crystal Display With Backlit |
| Protection | Against Wrong Wiring And Transient Over Voltages |
| Performance | Ultra, Ultra For Flow, And Classic |
| Measurement Types | Gauge, Differential, Or Absolute |
| Additional Features | Remote Display And Interface Options |
| Adjustment Options | Zero And Span Adjustment |
The with HART protocol converts input pressure signals into 4 to 20mA analogue output signal. The SE62H can be programmed via three buttons alternatively through PC. Following parameters can be adjusted : Zero, Span, Decimal Point, Damping, Display Mode, Restore Data and so on. For parameter setting and visualization of measured value, liquid crystal displays with backlit is available. The transmitter is protected against wrong wiring and transient over voltages.
Features :-
- Ultra, ultra for flow, and classic performance
- Gauge, differential or absolute measurements
- Remote Display and Interface options
- Zero and span adjustment
