10 Piece (MOQ)
| Business Type | Manufacturer, Exporter, Supplier |
| Brand Name | CBRO |
| Medium | Air and Non-combustible Gas |
| Range | Min. 0 – ±25 Pa, Max. 0 – ±4000 Range Mmwc |
| Click to view more | |
Product Details
Power Supply
10 ~ 35 V DC (2 Wires)
Accuracy
1% Up To 200 mm, : 0.25 % Up To 4000 mmWC
Electrocal Consumption
<10mA
Installation Direction
Vertical
Response Time
Field Adjustable 0.5~15s
Zero & Span Adjust
Digital Button With Led Indication.
Electrical Connection
2.5 Sqmm Cable Terminal
Protection Class
Ip65 / Flp / Clean Room (ss)
Temperature Drift
0.025% (Zero And Full Range Total)
Pressure Limit
10 X As Per Range, 10 psi (Exploded)*
Enclosure Size
Industrial Class Abs Or Aluminium Dia Cast
FEATURE:-
♦ Compact housing with IP 65 Protection Housing.
♦ Wide DP range ± 25Pa To 4000 mmWC.
♦ Re Ranging and calibrations can be done Thought Internal Keys and LED on site.
♦ +0.25 % Accuracy.
♦ Hi accuracy True-stable Digital Sensor, With Damping Facility.
♦ 4- 20 mA or 0 – 10 VDC Output available.
